Hotwire: Typeahead searching

Let’s build a collapsible search-as-you-type text box that expands to show its results in-line while searching, supports keyboard navigation and selection, and only submits requests to our server when there is a search term.

We’ll start with an out-of-the-box Rails installation that utilizes Turbo Drive, Turbo Frames, and Stimulus to then progressively enhance concepts and tools that are built directly into browsers. Plus, it’ll degrade gracefully when JavaScript is unavailable!

The code samples contained within omit the majority of the application’s setup. While reading, know that the application’s baseline code was generated via rails new. The rest of the source code from this article can be found on GitHub.

Our haystack

We’ll be searching through a collection of Active Record-backed Message models, with each row containing a TEXT column named body. Let’s use Rails’ scaffold generator to create application scaffolding for the Message routes, controllers, and model:

bin/rails generate scaffold Message body:text

For simplicity’s sake, our application will rely on SQL’s ILIKE-powered pattern matching. Once implemented, the experience could be improved by more powerful search tools (e.g. PostgresSQL’s full-text searching capabilities).

Searching for our needle

First, we’ll declare the searches#index route to handle our search query requests:

--- a/config/routes.rb
+++ b/config/routes.rb
  Rails.application.routes.draw do
    resources :messages
+  resources :searches, only: :index
    # For details on the DSL available within this file, see https://guides.rubyonrails.org/routing.html
  end

Next, add a <header> element to our layout. While we’re at it, we’ll also wrap the <%= yield %> in a <main> element so that it’s the <header> element’s sibling:

--- a/app/views/layouts/application.html.erb
+++ b/app/views/layouts/application.html.erb
@@ -15,6 +15,21 @@
    <body>
+    <header>
+    </header>
+
-    <%= yield %>
+    <main><%= yield %></main>
    </body>
  </html>

Within the <header>, we’ll nest a <form> element that submits requests to the searches#index route:

--- a/app/views/layouts/application.html.erb
+++ b/app/views/layouts/application.html.erb
@@ -15,6 +15,21 @@
    <body>
      <header>
+      <form action="<%= searches_path %>">
+      </form>
      </header>

      <main><%= yield %></main>
    </body>
  </html>

When declared without a [method] attribute, <form> elements default to [method="get"]. Since querying is an idempotent and safe action, the <form> element will make GET HTTP requests when submitted.

Within the <form>, we’ll declare an <input type="search"> to capture the query and a <button> to submit the request:

--- a/app/views/layouts/application.html.erb
+++ b/app/views/layouts/application.html.erb
        <form action="<%= searches_path %>">
+        <label for="search_query">Query</label>
+        <input id="search_query" name="query" type="search">
+
+        <button>
+          Search
+        </button>
        </form>

Within the searches#index controller action, we’ll transform the ?query= parameter into an argument for our Message.containing Active Record scope.

class SearchesController < ApplicationController
  def index
    @messages = Message.containing(params[:query])
  end
end

The Message.containing scope interpolates the query argument’s text into an ILIKE statement with leading and trailing % wildcard operators:

--- a/app/models/message.rb
+++ b/app/models/message.rb
  class Message < ApplicationRecord
+  scope :containing, -> (query) { where <<~SQL, "%" + query + "%" }
+    body ILIKE :query
+  SQL
  end

Within the corresponding app/views/searches/index.html.erb template, we’ll render an <a> element for each result. We’ll pass each Message#body to highlight so that the portions of the text that match the search term are wrapped with <mark> elements.

<h1>Results</h1>

<ul>
  <% @messages.each do |message| %>
    <li>
      <%= link_to highlight(message.body, params[:query]), message_path(message) %>
    </li>
  <% end %>
</ul>

Enhancing our search

Currently, submitting our search <form> navigates our application, resulting in a full-page transition. We can improve upon that experience by navigating part of our page instead.

Turbo Frames are a predefined portion of a page that can be updated upon request. Any requests from inside a frame from links or forms are captured, and the frame’s contents are automatically updated after receiving a response. Frames are rendered as <turbo-frame> Custom Elements, and have their own set of attributes and properties. They can be navigated by descendant <a> and <form> elements or by <a> and <form> elements elsewhere in the document.

Let’s render our search results into a <turbo-frame> element. We’ll add the element as a sibling to our header’s <form> element, making sure to give it an [id] attribute:

--- a/app/views/layouts/application.html.erb
+++ b/app/views/layouts/application.html.erb
          <button type="submit">
            Search
          </button>
        </form>
+
+      <turbo-frame id="search_results"></turbo-frame>
      </header>
    </body>

To navigate it, we’ll target it with our search <form> by declaring the data-turbo-frame=“search_results” attribute:

--- a/app/views/layouts/application.html.erb
+++ b/app/views/layouts/application.html.erb
@@ -17,7 +17,7 @@
-      <form action="<%= searches_path %>">
+      <form action="<%= searches_path %>" data-turbo-frame="search_results">
          <label for="search_query">Query</label>
          <input id="search_query" name="query" type="search">

          <button>
            Search
          </button>
        </form>

        <turbo-frame id="search_results"></turbo-frame>

Whenever our <form> element submits, Turbo will navigate the <turbo-frame id="search_results"> based on the <form> element’s action attribute. For example, when a user fills in the <input type="search"> element with “needle” and submits the <form>, Turbo will set the <turbo-frame> element’s src attribute and navigate to /searches?query=needle. The request’s Accept HTTP Headers will be similar to what the browser would submit had it navigated the entire page.

In response, our server will handle the request like any other HTML request, with one additional constraint: we’ll need to make sure that our response HTML contains a <turbo-frame> element with an [id] attribute that matches the frame in the requesting page.

To meet that requirement, we’ll wrap the contents of the searches#index template in a matching <turbo-frame id="search_results"> element:

--- a/app/views/searches/index.html.erb
+++ b/app/views/searches/index.html.erb
+<turbo-frame id="search_results">
    <h1>Results</h1>

    <ul>
      <% @messages.each do |message| %>
        <li>
          <%= link_to highlight(message.body, params[:query]), message_path(message) %>
        </li>
      <% end %>
   </ul>
+</turbo-frame>

To ensure sure that the request’s <turbo-frame> element [id] is consistent with to the response’s, we’ll encode the identifier into the ?turbo_frame= query parameter as part of the <form> element’s [action] attribute:

--- a/app/views/layouts/application.html.erb
+++ b/app/views/layouts/application.html.erb
@@ -17,7 +17,7 @@
-      <form action="<%= searches_path %>" data-turbo-frame="search_results">
+      <form action="<%= searches_path(turbo_frame: "search_results") %>" data-turbo-frame="search_results">
          <label for="search_query">Query</label>
          <input id="search_query" name="query" type="search">

          <button>
            Search
          </button>
        </form>

        <turbo-frame id="search_results"></turbo-frame>

Then we’ll encode the value into the rendered <turbo-frame> element’s [id] with a default value when the param is missing:

--- a/app/views/searches/index.html.erb
+++ b/app/views/searches/index.html.erb
-<turbo-frame id="search_results">
+<turbo-frame id="<%= params.fetch(:turbo_frame, "search_results") %>">

When an end-user clicks on a <a> element in the results, we’ll want to navigate the page, not the <turbo-frame> element that contains the <a>. To ensure that, we have two options: annotate each <a> with the [data-turbo-frame="_top"] attribute, or annotate the application layout template’s <turbo-frame> element with the [target="_top"] attribute.

For the sake of simplicity, let’s annotate the custom <turbo-frame> element with the custom [target] attribute instead of annotating the standards-based <a> element with a data-prefixed custom attribute:

--- a/app/views/layouts/application.html.erb
+++ b/app/views/layouts/application.html.erb
-      <turbo-frame id="search_results"></turbo-frame>
+      <turbo-frame id="search_results" target="_top"></turbo-frame>

Now that we’re overlaying our results on top of the rest of the page, we’ll only want to do so when the end-user is actively searching. We’ll also want to avoid needless requests to the server with empty query text.

Lucky for us, browsers provide a built-in mechanism to prevent bad <form> submissions and to surface a field’s correctness: Constraint Validations!

In our case, there are two ways that a search can be invalid:

The query <input> element is completely blank.
The query <input> element has a value, but that value is comprised of entirely empty text characters.

To consider those states invalid, render the <input> with required and pattern attributes:

--- a/app/views/layouts/application.html.erb
+++ b/app/views/layouts/application.html.erb
        <form action="<%= searches_path(turbo_frame: "search_results") %>" data-turbo-frame="search_results">
          <label for="search_query">Query</label>
-        <input id="search_query" name="query" type="search">
+        <input id="search_query" name="query" type="search" pattern=".*\w+.*" required>

By default, browsers will communicate a field’s invalidity by rendering a field-local tooltip message. While it’s important to minimize the number of invalid HTTP requests sent to our server, a type-ahead search box works best when users can incrementally make changes to the query string. In our case, a validation message could disruptive or distract a user mid-search.

To have more control over the validation experience, we’ll need to write some JavaScript. Let’s create app/javascript/controllers/form_controller.js to serve as a Stimulus Controller:

import { Controller } from "@hotwired/stimulus"

export default class extends Controller {
}

Next, we’ll need to listen for browsers’ built-in invalid events to fire. When they do, we’ll route them to the form controller as a Stimulus Action named hideValidationMessage:

--- a/app/views/layouts/application.html.erb
+++ b/app/views/layouts/application.html.erb
      <header>
-      <form action="<%= searches_path(turbo_frame: "search_results") %>" data-turbo-frame="search_results">
+      <form action="<%= searches_path(turbo_frame: "search_results") %>" data-turbo-frame="search_results"
+        data-controller="form" data-action="invalid->form#hideValidationMessage:capture">
          <label for="search_query">Query</label>

One quirk of invalid events is that they do not bubble up through the DOM. To account for that, our form controller will need to act on them during the capture phase. Stimulus supports the :capture suffix as a directive to hint to our action routing that the controller’s action should be invoked during the capture phase of the underlying event listener.

Once we’re able to act upon the invalid event, we’ll want the form#hideValidationMessage action to prevent the default behavior to stop the browser from rendering the validation message.

--- a/app/javascript/controllers/form_controller.js
+++ b/app/javascript/controllers/form_controller.js
  import { Controller } from "@hotwired/stimulus"

  export default class extends Controller {
+  hideValidationMessage(event) {
+    event.stopPropagation()
+    event.preventDefault()
+  }
  }

When an ancestor <form> element contains fields that are invalid, it will match the :invalid pseudo-selector. By rendering the search results <turbo-frame> element as a direct sibling to the <form> element, we can incorporate the :invalid state into the sibling element’s style, and hide it.

--- a/app/assets/stylesheets/application.css
+++ b/app/assets/stylesheets/application.css
*= require_tree .
*= require_self
*/
+
+.empty\:hidden:empty                                { display: none; }
+.peer:invalid ~ .peer-invalid\:hidden               { display: none; }

--- a/app/views/layouts/application.html.erb
+++ b/app/views/layouts/application.html.erb
    <header>
-      <form action="<%= searches_path(turbo_frame: "search_results") %>" data-turbo-frame="search_results"
+      <form action="<%= searches_path(turbo_frame: "search_results") %>" data-turbo-frame="search_results" class="peer"
        data-controller="form" data-action="invalid->form#hideValidationMessage:capture">
        <label for="search_query">Query</label>

--- a/app/views/layouts/application.html.erb
+++ b/app/views/layouts/application.html.erb
-      <turbo-frame id="search_results" target="_top"></turbo-frame>
+      <turbo-frame id="search_results" target="_top" class="empty:hidden peer-invalid:hidden"></turbo-frame>
    </header>

Navigating the results

Now that our search results are rendered onto the page, we’ll want to navigate through them with our keyboard’s direction keys. The Web Accessibility Initiative - Accessible Rich Internet Applications (WAI-ARIA) Authoring Practices outline a pattern for this type of behavior: role=“combobox”.

We’ll depend on the @github/combobox-nav package to progressively enhance our search results by outsourcing keyboard navigation and selection management.

Wiring-up the controller

Since we’re overriding the way that browsers prompt users with a list of choices when filling out a text box, we’ll start by signalling to browsers that our <input type="search"> can skip autocompletion by declaring autocomplete=“off”:

--- a/app/views/layouts/application.html.erb
+++ b/app/views/layouts/application.html.erb
    <body>
      <header>
        <form action="<%= searches_path(turbo_frame: "search_results") %>" data-turbo-frame="search_results" class="peer"
          data-controller="form" data-action="invalid->form#hideValidationMessage:capture">
          <label for="search_query">Query</label>
-        <input id="search_query" name="query" type="search" pattern=".*\w+.*" required>
+        <input id="search_query" name="query" type="search" pattern=".*\w+.*" required autocomplete="off">

Next, we’ll create a combobox Stimulus Controller and import the @github/combobox-nav package through Skypack:

import { Controller } from "@hotwired/stimulus"
import Combobox from "https://cdn.skypack.dev/@github/combobox-nav"

export default class extends Controller {
}

Our controller needs an element within the browser’s document to attach its behavior to, so we’ll declare [data-controller="combobox"] on an element. In this case, it’s crucial that the element is an ancestor of both our <input type="search"> and our <turbo-frame id="search_results"> elements. Since the <input type="search"> element’s ancestor <form> is the <turbo-frame id="search_results"> element’s sibling, their <header> ancestor will do the trick:

--- a/app/views/layouts/application.html.erb
+++ b/app/views/layouts/application.html.erb
    <body>
-    <header>
+    <header data-controller="combobox">
        <form action="<%= searches_path(turbo_frame: "search_results") %>" data-turbo-frame="search_results" class="peer"
          data-controller="form" data-action="invalid->form#hideValidationMessage:capture">
          <label for="search_query">Query</label>

In order to construct and attach a Combobox instance, we’ll need two elements: a [role="combobox"] element and a [role="listbox"] element with. Stimulus Targets afford controllers with direct references to elements with the matching attributes. We’ll create targets to access the input and the list:

--- a/app/javascript/controllers/combobox_controller.js
+++ b/app/javascript/controllers/combobox_controller.js
  import { Controller } from "@hotwired/stimulus"
  import Combobox from "https://cdn.skypack.dev/@github/combobox-nav"

  export default class extends Controller {
+  static get targets() { return [ "input", "list" ] }
  }

We’ll annotate elements in our templates to coincide with each target declaration. First, we’ll declare [data-combobox-target="input"] on our <input type="search">:

--- a/app/views/layouts/application.html.erb
+++ b/app/views/layouts/application.html.erb
    <body>
      <header data-controller="combobox">
        <form action="<%= searches_path(turbo_frame: "search_results") %>" data-turbo-frame="search_results" class="peer"
          data-controller="form" data-action="invalid->form#hideValidationMessage:capture">
          <label for="search_query">Query</label>
-        <input id="search_query" name="query" type="search" pattern=".*\w+.*" required autocomplete="off">
+        <input id="search_query" name="query" type="search" pattern=".*\w+.*" required autocomplete="off"
+          data-combobox-target="input">

According to the @github/combobox-nav documentation, there are two requirements for the list:

Each option needs to have role="option" and a unique id

The list should have role="listbox"

To meet those requirements, we’ll declare [role="listbox"] and [data-combobox-target="list"] on the searches/index template’s <ul> element. For each of the <ul> element’s descendant <a> elements will declare the [role="option"] attribute, and make sure each has a unique [id] attribute:

--- a/app/views/searches/index.html.erb
+++ b/app/views/searches/index.html.erb
  <turbo-frame id="<%= params.fetch(:turbo_frame, "search_results") %>">
    <h1>Results</h1>

-  <ul>
+  <ul role="listbox" data-combobox-target="list">
      <% @messages.each do |message| %>
        <li>
-        <%= link_to highlight(message.body, params[:query]), message_path(message) %>
+        <%= link_to highlight(message.body, params[:query]), message_path(message),
+              id: dom_id(message, :search_result), role: "option" %>
        </li>
      <% end %>
    </ul>

Now that our controller has direct access to the necessary element, and those elements meet the markup requirements for @github/combobox-nav, we can wire-up our Stimulus Actions to start and stop keyboard event interception.

We’ll want our controller to start intercepting keyboard events whenever:

The <input type="search"> element gains focus
The [role="listbox"] element is present and contains search results to navigate

To cover the first case, we’ll declare a start() action:

--- a/app/javascript/controllers/combobox_controller.js
+++ b/app/javascript/controllers/combobox_controller.js
  export default class extends Controller {
    static get targets() { return [ "input", "list" ] }
+
+  start() {
+    this.combobox?.destroy()
+
+    this.combobox = new Combobox(this.inputTarget, this.listTarget)
+    this.combobox.start()
+  }
  }

The action makes use of the optional chaining operator to safely destroy any previously instantiated Combobox instances so that each start() action operates without stale references.

In order to route focus events to our controller’s start() action, we’ll need to declare a focus->combobox#start descriptor on the <input type="search"> element:

--- a/app/views/layouts/application.html.erb
+++ b/app/views/layouts/application.html.erb
@@ -10,11 +10,12 @@
    </head>

    <body>
      <header data-controller="combobox">
        <form action="<%= searches_path(turbo_frame: "search_results") %>" data-turbo-frame="search_results" class="peer"
          data-controller="form" data-action="invalid->form#hideValidationMessage:capture">
          <label for="search_query">Query</label>
          <input id="search_query" name="query" type="search" pattern=".*\w+.*" required autocomplete="off"
-          data-combobox-target="input">
+          data-combobox-target="input" data-action="focus->combobox#start">

To cover the second case, we’ll implement a listTargetConnected() callback to fire whenever our [data-combobox-target="list"] element is connected to the document:

--- a/app/javascript/controllers/combobox_controller.js
+++ b/app/javascript/controllers/combobox_controller.js
  export default class extends Controller {
    static get targets() { return [ "input", "list" ] }
+
+  listTargetConnected() {
+    this.start()
+  }
+
    start() {

We’ll stop intercepting keyboard events whenever the <input type="search"> element loses focus. To do so, we’ll add a stop() action to our controller:

--- a/app/javascript/controllers/combobox_controller.js
+++ b/app/javascript/controllers/combobox_controller.js

      this.combobox = new Combobox(this.inputTarget, this.listTarget)
      this.combobox.start()
    }
+
+  stop() {
+    this.combobox?.stop()
+  }
  }

Next, we’ll declare a focusout->combobox#stop descriptor on our <input type="search"> element so that our controller’s stop() is invoked whenever a focusout event fires:

--- a/app/views/layouts/application.html.erb
+++ b/app/views/layouts/application.html.erb
          <label for="search_query">Query</label>
          <input id="search_query" name="query" type="search" pattern=".*\w+.*" required autocomplete="off"
-          data-combobox-target="input" data-action="focus->combobox#start">
+          data-combobox-target="input" data-action="focus->combobox#start focusout->combobox#stop">

Finally, whenever the controlled element is disconnected from the document, we’ll destroy the Combobox instance:

--- a/app/javascript/controllers/combobox_controller.js
+++ b/app/javascript/controllers/combobox_controller.js
    static get targets() { return [ "input", "list" ] }

+  disconnect() {
+    this.combobox?.destroy()
+  }
+
    listTargetConnected() {
      this.start()
    }

Visually indicating selection

Navigating a [role="combobox"] element moves a selection cursor, instead of the document’s focus. Whenever ↑ or ↓ keys are pressed, the Combobox instance will set [aria-selected="true"] on the current [role="option"] element and [aria-selected="false"] on all other [role="option"] elements.

To add a visual cue that the selection has changed, we’ll declare an aria-selected:outline-black class inspired by Tailwind CSS:

--- a/app/assets/stylesheets/application.css
+++ b/app/assets/stylesheets/application.css
 .empty\:hidden:empty                                { display: none; }
 .peer:invalid ~ .peer-invalid\:hidden               { display: none; }
+.aria-selected\:outline-black[aria-selected="true"] { outline: 2px dotted black; }

Next, we’ll add that class to our <a> search result elements:

--- a/app/views/searches/index.html.erb
+++ b/app/views/searches/index.html.erb
@@ -1,10 +1,11 @@
      <% @messages.each do |message| %>
        <li>
          <%= link_to highlight(message.body, params[:query]), message_path(message),
-              id: dom_id(message, :search_result), role: "option" %>
+              id: dom_id(message, :search_result), role: "option", class: "aria-selected:outline-black" %>
        </li>
      <% end %>

Searching while typing

Whenever the end-user enters text into <input type="search"> element, an input event fill fire fore each keystroke and bubble up.. When the <input> element’s text changes, we’ll refresh the search results by submitting the corresponding <form> element. Since the <form> element targets the <turbo-frame id="search_results">, the frame will navigate automatically whenever the form submits.

To submit the <form> after each keystroke, we’ll declare an action descriptor to route all input events to the form#submit action:

--- a/app/views/layouts/application.html.erb
+++ b/app/views/layouts/application.html.erb
@@ -17,11 +17,11 @@
    <body>
      <header>
        <form action="<%= searches_path(turbo_frame: "search_results") %>" data-turbo-frame="search_results" class="peer"
-        data-controller="form" data-action="invalid->form#hideValidationMessage:capture">
+        data-controller="form" data-action="invalid->form#hideValidationMessage:capture input->form#submit">
          <label for="search_query">Query</label>
          <input id="search_query" name="query" type="search" pattern=".*\w+.*" required>

          <button>
            Search
          </button>
        </form>

We’ll declare [data-form-target="submit"] on the <form> element’s <button>, so that the form controller instance can access it as a Target:

--- a/app/views/layouts/application.html.erb
+++ b/app/views/layouts/application.html.erb
@@ -17,11 +17,11 @@
-        <button>
+        <button data-form-target="submit">
            Search
          </button>

We’ll declare the submit target within the form controller, then implement the submit() action to reference the new target and submit the <form> by clicking the <button> on the end-user’s behalf:

--- a/app/javascript/controllers/form_controller.js
+++ b/app/javascript/controllers/form_controller.js
  import { Controller } from "@hotwired/stimulus"

  export default class extends Controller {
+  static get targets() { return [ "submit" ] }
+
+  submit() {
+    this.submitTarget.click()
+  }
+
    hideValidationMessage(event) {
      event.stopPropagation()
      event.preventDefault()
    }
  }

Since we’ll be automatically submitting the form on each keystroke, we have an opportunity to hide the submit button. We’ll use JavaScript to set the hidden attribute on the element. By deferring the [hidden] attribute to JavaScript, we can ensure that the element is visible whenever end-users are browsing without JavaScript enabled.

--- a/app/javascript/controllers/form_controller.js
+++ b/app/javascript/controllers/form_controller.js
  import { Controller } from "@hotwired/stimulus"

  export default class extends Controller {
    static get targets() { return [ "submit" ] }
+
+  connect() {
+    this.submitTarget.hidden = true
+  }

    submit() {

Finally, submitting the <form> on every keystroke results in a cascade of sequential HTTP requests. In that scenario, the majority of the intermediate responses could be ignored. To limit the number of concurrent requests, we’ll add limitations to ensure that a submission occurs at most once every 200 milliseconds. We’ll add a client-side dependency on Lodash.debounce through Skypack. Once that function is available, we’ll re-bind the form#submit action to the debounced version:

--- a/app/javascript/controllers/form_controller.js
+++ b/app/javascript/controllers/form_controller.js
  import { Controller } from "@hotwired/stimulus"
+import debounce from "https://cdn.skypack.dev/lodash.debounce"

  export default class extends Controller {
    static get targets() { return [ "submit" ] }
+
+  initialize() {
+    this.submit = debounce(this.submit.bind(this), 200)
+  }

    connect() {
      this.submitTarget.hidden = true
    }

Wrapping up

We started with an out-of-the-box Rails application generated by rails new, then implemented a collapsible search-as-you-type experience. The <input type="search"> element’s container expands to show its results in-line while searching, supports keyboard navigation and selection, and only submits requests to the server when a search term is present.

We never encode our search request or response into JSON, and our client communicates with our server without any calls to XMLHttpRequest or fetch from within our application code.

On top of all that, we’ve implemented the experience with semantically meaningful elements like <form>, <input type="search">, and <mark>!
